Ensure that the remote control handle battery is installed. (see diagram below)
NOTE: Remove large objects over 32mm in size with a net to prevent excessive blocking of Pondmonsta
during operation. It is normal for Pondmonsta to block and require clearing occasionally. Pond Monsta
has been designed so that this requires a minimum of time and effort (see ‘Clearing Blockages’ page 10)
1. Plug in RCD (not supplied).
2. Plug in fitted three pin RF receiver plug.
3. Plug in RF receiver connecter plug.
4. Connect hose to outlet hosetail firmly (a hose clip may be used to secure not supplied)
5. Choose Collector recycling option / position for Collector outlet returns. (see page 10)
6. Place hose in Collector locater
7. Connect hose and cable to hose cable clips. Adjust so that the hose is level with the
water surface when the Monsta is fully submerged.
8. Adjust pole by twisting and locking to a comfortable height.
9. Switch on mains supply, standby light will show red on the RF receiver.
10. Submerge Monsta fully until air stops releasing from air outlet (the Monsta will not
pump effectively until all air is released)
11. Compress safety button and squeeze lever to activate pumping
12. Waste will now start to flow into the Collector, it is recommended that the higher shelf
areas are cleaned first. Always move the Pond Monsta in a slow back and forth action to
prevent disturbing the sediment and waste.
13. Secondly clean the base of the pond, again in a slow back and forth motion using the
clear hose as a visual guide to indicate which areas have been cleared.
14. When the Collector basket is full / overflowing, turn of the Pondmonsta by releasing
the handle and remove the collected debris to waste or compost.
HOW TO USE POND MONSTA HOW TO USE POND MONSTA
11
4
13
8
7
12
6
5
14
3
9
10
1
2
Water level MUST submerge the
Air Outlet before starting Monsta.
Minimum water depth = 30cm
Maximum water depth = 5 metres
MINIMUM START DEPTH
HANDLE ACTIVATION & BATTERY INSTALLATION
1. DEPRESS SAFETY BUTTON
2. SQUEEZE LEVER
HANDLE REMOTE CONTROL
BATTERY LOCATION
MIN: 30cm
MAX: 5 metres
AIR OUTLET
WARNING: DO NOT SUBMERGE THE HANDLE IN THE POND
8 9
