Blakeslee B-12 Service & Parts Manual

M-5-3330-D & M-5-18769 MIXER TRANSMISSION, MOTOR AND HOUSING
Item
No.
Part
No.
Description
No.
Reqd.
Φ la M5-3330-D TRANSMISSION, Reconditioned, Exchange 1
Φ1b
M5-18769 TRANSMISSION, Reconditioned 1
2 M3-1961 TOP COVER, Gearbox and Motor Housing 1
3 W1-12549 SCREWS, 1/4 x 1-1/4" Flat Head Machine 3
4a M4-1958 HOUSING, Motor, Cast Aluminum (12 Qt. Models) 1
4b M-3-72974 HOUSING, Motor, Cast Aluminum (20 Qt. Models) 1
4c M-3-72975 HOUSING, Motor, Cast Aluminum (30 Qt. Models) 1
5 M1-3451 COVER PLATE, for Rear of Motor Housing 1
6 W0-20279 SCREWS, 10-24 x 3/8" R. H. Cad. Plated 4
7a M2-3329 NAMEPLATE, M 5-3330 Transmission Tog. Switch-
type, 1 PH only 1
7b M2-3327 NAMEPLATE & TIMER, 1 PH & 3 PH 1
7c M2-3325 NAMEPLATE, Tog. Switchtype w/Overload 1 PH Only 1
8 M0-17379 PLUG, Snaphole, for M2-1458 1
9 M0-17380 SNAP RING 1
10 M 2-14 58 LEVER, Gearshift 1
11 M-1-15310 SCREWS, 8/32 x 3/8" Pan Head 4
12 SEE CHART CONTROLLER 1
12a W0-95645 TIMER KNOB 1
13a M1-15112 MOTOR 1/4 H. P., 1 Phase (12 Qt. Models) 110V only 1
13b W0-189 03 210 M.F.D. CAPACITOR (for M1-15112 Motor only) 1
13c M1-15113 MOTOR 1/4 H. P., 3 Phase (12 Qt. Models) 1
13d M1-15117 MOTOR 1/2 H. P., 1 Phase (20 Qt. Models) 1
13e M0-20274 270-325 M.F.D. CAPACITOR (for M1-15117 Motor only) 1
13f M1-15118 MOTOR 1/2 H. P., 3 Phase (20 Qt. Models) 1
13g M1-15119 MOTOR 3/4 H. P., 1 Phase (30 Qt. Models) 1
13h W0-18904 540 M.F.D. CAPACITOR (for M1-15119 Motor only) 1
13i M1-15120 MOTOR 3/4 H. P., 3 Phase (30 Qt. Models) 1
13j W0-18512 MOTOR 3/4 H. P., 1 Phase, 1200 RPM Spl. Low-
Speed Feature (30 Qt. Models) 1
13k W0-18504 MOTOR 3/4 H. P., 3 Phase, 1200 RPM Spl. Low-
Speed Feature (30 Qt. Models) 1
14 M1-3573 SCREWS, 3/8 x 1" Socket Head Machine 4
15 M1-3427 GASKET 1
16 M1-15358 KEY, 1/8 x 1/8" 1
17 M1-15141 "O" RING 1
18 M1-15144 WASHER, 1/2 x 3/4" Copper Asbestos 1
19a M1-1491 SPACER (A. 0. Smith Motor) 1
19b M1-1539 SPACER (Howell Motor & Marathon) 1
20 M1-15143 OIL SEAL 1
21 M-1252 WORM 1
22 M1-15142 WASHER 1
23 M1-15145 NUT 1
24 M1-15366 CABLE ASSY. - Motor to Switch (3 ph. - 208/230V only) 1
24a M1-18594 CABLE ASSY. - Motor to Switch (3 ph. - 440/480V only) 1
25 M2-3427 GASKET Motor to Transmission 1
25a M0-18785 GASKET MATERIAL (Permatex Type 3D), 16 Oz. Can 1
26 M1-95654 SWITCH GUARD 1
27 M1-95650 CAUTION LABEL 1
*M5-3330-D TRANSMISSION is used with all machines with an M3-1961 Top Cover, up to
Serial #1 .
M5-18769 TRANSMISSION is used from Serial #1 & up.
SPECIFY MACHINE SERIAL NO. WHEN ORDERING PARTS
25
