Blakeslee B-12 Service & Parts Manual

MODEL F-30 COLUMN AND BASE ASSEMBLY
Item
No.
Part
No. Description
No.
Reqd.
F30 with
M5-
3330 or
M5-18769
Transmission
F30
with
M5-
1505
Transmission
1
M
-
3
-
72877
BASE, Floor Type
1
x
x
2 M1-15320 CAPSCREW, 1/2 x 1-3/4" 4 x x
3 M1-15317 LOCKWASHER, 1/2" Split 4
X
x
4 M1-15323 LOCKNUT, 3/8" Hex 4
X
x
5 W0-16364 KEY, 3/16 x 3/16 sq. x 1-1/6" lg. 1
X
x
6 M1-3442 BOTTOM COVER 1
X
x
7 M4-1997 COLUMN 1
X
7 M4-1412 COLUMN 1 x
8 M4-1998 BOWL SUPPORT 1
X
8 M4-1414-G BOWL SUPPORT 1 x
9 M1-1991 BOWL PIN 2
X
x
10 M1-1603 BUSHING, Nylon 1
X
x
11 M3-3305 BAR, Bowl Support Guide 1
X
11 M2-1424-F BAR, Bowl Support Guide 1 x
12 M2-3312 STRAP, Bowl Support Guide 2
X
12 M2-1425 STRAP, Bowl Support 2 x
13 M1-15056 SCREW, 3/8 x 7/8" F. H. Machine 4
X
x
14 M2-1995 SANITARY SHIELD 1
X
14 M2-1461 SANITARY SHIELD 1 x
15 M1-15339 SCREW, 3/8 x 2" F. H. Machine 6
X
x
17 W1-12821 COLLAR, 5/8" Set 1
X
x
18 M3-3308 LEVER, Bowl Left 1
X
18 M3-1937 LEVER, Bowl Left 1 x
19 M-0-99066 KNOB, Bowl Lift Handle 1
X
x
20 M2-1969 DRAG LINK 1
X
20 M2-1319 DRAG LINK 1 x
21 M1-1967 CRANK 1
X
21 M1-1419 CRANK 1 x
21 M1-1528 STOP, Crank 1 x
22 M2-1968 ROD, Spring 1
X
22 M2-1514 ROD, Spring 1 x
23 M1-1322 GUIDE, Rocker 1
X
x
24 M1-1346 WASHER, Spring 1
X
x
25 M1-1320 SPRING 1
X
x
26 M1-1994 SPRING, Balance 1
X
x
27 M1-1515 HEMISPHERICAL SPRING PERCH 1
X
x
28 M2-3314 ENCLOSURE PANEL, Rear 1
X
28 M4-1457 ENCLOSURE PANEL, Rear 1 x
29 M1-3307 PANEL ENCLOSURE, Base 1
X
x
30 M1-1516 WASHER, 3/8" Flat 3
X
x
31 W0-16365 LOCKNUT, 3/8-16 Flex 1
X
x
32 W1-16361 PIN, 1/8 x 3/4" Cotter 1
X
x
33 M1-7117 SETSCREW, 5/16 x 3/8" Soc. Hd. 1
X
x
35 SCREW, Sheet Metal 1
X
x
36 P1-5052 PLATE, Data 1
X
x
37 W2-20878 MOTOR REQUIREMENT NAME PLATE 1
X
x
38 W1-8096 SCREW, #4 x 1/4 Self-Tapping 4
X
x
39 M-1-73481 PLASTIC LEG CUP 4
X
x
SPECIFY MACHINE SERIAL NO. WHEN ORDERING PARTS
27

Blakeslee B-12 Specifications

General

Brand	Blakeslee
Model	B-12
Category	Mixer
Language	English
