Blakeslee B-12 Service & Parts Manual

MODELS B-12, W-12, B-20, W-20, F-20, U-20 SERIES COLUMN AND BASE ASSEMBLY
USED ON Item
No.
Part
No.
Description
No.
Reqd
B12
W12
B20 W20
F20 U20
1
M
-
4
-
72871
BASE, Bench Type
1
x
x
x
x
1 M-4-72871 BASE, Floor Type 1
x
2 Wl-9548 CAPSCREW, 3/8 x 1-3/4" 4
X
x x x
2 Ml-15320 CAPSCREW, 1/2 x 1-3/4" 4
x x
3 M4-1504 BASE, Wall Type 1
x
x
4 M4-1506 BRACKET, Wall Mount 1
x x
5 Ml-1361 SUPPORT STUD, Attachment Mount 2
x
x
6 Ml-1462 SCREEN, Vinyl 1
X
x x x x
7 M4-1413-B COLUMN 1
X
x
7 M4-1416 COLUMN 1
x x
7 M4-1557 COLUMN 1
x x
8 M4-1418 BOWL SUPPORT 1
X
x
8 M4-1417 BOWL SUPPORT 1
x x x x
9 M1-1348-B BOWL PIN 2
X
x x x x x
10 Ml-1603 BUSHING, Nylon 1
X
x x x x x
11 M2-1428-B BAR, Bowl Support Guide 1
X
x x x
11 M2-1437-B BAR, Bowl Support Guide 1
x x
12 Ml-1427 STRAP, Lock Bowl Support 2
X
x x x x x
13 Ml-15339 SCREW, 3/8 x 2" F. H. Mach. 4
X
x x x x x
14 Ml-15056 SCREW, 3/8 x 7/8" F. H. Mach. 4
X
x x x x x
15 M2-1436 LEVER, Bowl Lift Handle 1
X
x x x
15 M3-1315 LEVER, Bowl Lift Handle 1
x x
16 M-0-99066 KNOB, Bowl Lift Handle 1
X
x x x
16 M-0-99066 KNOB, Bowl Lift Handle 1
x x
17 M2-1426 DRAG LINK 1
X
x
17 M2-1422 DRAG LINK 1
x x
17 M2-1420 DRAG LINK 1
x x
18 Ml-1344 CRANK w/SETSCREW 1
X
x x x
18 Ml-1419 CRANK w/SETSCREW 1
x x
19 Ml-1528 CRANK STOP w/SETSCREW 1
x x
20 Ml-1322 GUIDE, Rocker 1
X
x x x x x
21 Ml-1320 SPRING 1
X
x x x x x
22 Ml-1346 WASHER, Spring 1
X
x x x x x
23 M2-1431 PANEL, Column Enclosure 1
X
x
23 M2-3359 PANEL, Column Enclosure 1
x x
23 M4-1457 PANEL, Column Enclosure 1
x x
24 Ml-18926 CABINET STAND w/Castors & Att. Holders
1
x
25 Ml-15102 CASTORS w/BRAKE 4
x
26 Ml-3538 WASHER, 3/8" Flat 3
X
x x x x x
27 Wl-7657 CAPSCREW, 1/4 x 1-1/4" 1
X
x x x
28 W0-7012 NUT, 1/4" Hex 1
X
x x x
29 Ml-15346 COLLAR, 1/2" Set 1
X
x x x
30 Wl-16361 PIN, 1/8 x 3/4" Cotter 2
X
x x x x x
31 Ml-15323 LOCKNUT, 3/8" Hex 5
X
x x x x x
32 Ml-15385 KEY, 1/8 x 1/8 sq. x 1" lg. 2
X
x x x
32 Ml-15387 KEY, 3/16 x 3/16 sq. x 1-5/8" lg. 2
x x
33 Ml-15095 CAPSCREW, 3/8 x 2-1/4" Full Thread 1
X
x x x x x
34 W1-5994 LOCKWASHER, 3/8" Split 4
X
x x x
34 Ml-15317 LOCKWASHER, 1/2" Split 4
x x
35 Ml-3476 SPLASH GUARD 1
x x x x
36 M1-15345 PIN, 1/8 x 9/16" Drive 1
X
x x x x x
37 Ml-3514 SCREW, 10-24 x 3/8" Rd.Hd.Self Tapping 2
x
x x
38 Ml-18562 3 WIRE CORD, Rubber Covered 1 Single phase models only
38A MI-15369 4 WIRE CORD, Rubber Covered 1 3 phase models only 208/240 only
38B Ml-18563 CORD SET ASSY. 1 3 phase only 440/480 only
39 Pl-17212 3 PRONG PLUG 1 Single phase models only
39A Pl-17213 4 PRONG PLUG 1 3 phase models only
40 Pl-17227 CABLE CONNECTOR 1
41 Pl-5052 PLATE, Data 1 x x x x x x
42 W2-20878 POWER REQUIREMENT NAMEPLATE 1 x x x x x x
43 Wl-8096 SCREW, #4 x 1/4 Self-Tapping 4 x x x x x x
44
M
-
1
-
73480
PLASTIC LEG CUP
4
x
SPECIFY MACHINE SERIAL NO. WHEN ORDERING PARTS
29
