CABINETRY PREPARATION FLUSHMOUNT
CABINETRY MATERIALS MUST BE SUITABLE TO WITHSTAND
TEMPERATURES UP TO 90°C
Dimensions illustrated are for
ushmount installation.
558
594
598
499
573
598
450
602
400
80
23
598
560
602
450
100
100
450
560
5
5
Provide a support 5mm thick
to each side of the cabinety to
support the oven so it’s not sitting
on the lower bracket (Drip Lip)
under the door.
