Operating manual BDC-133M / BDC-133H
GB
Vacuum cleaner description
Optional kits
Please contact the manufacturer's sales network for
information on optionals.
Instructions for installing the optional are included in the
conversion kit.
WARNING!
Use only supplied and authorised genuine spare
parts.
Accessories
Various accessories are available; refer to the manufacturer's
accessory catalogue.
WARNING!
Use only genuine accessories supplied and
authorised by the manufacturer.
Packing and unpacking
Dispose of the packing materials in compliance with the laws
in force.
Figure 3
Model BDC-133M
A (mm) 700
B (mm) 860
C (mm) 1750
Weight with packing (kg) 86
Unpacking, moving, use and storage
Operate on at, horizontal surfaces.
The load-bearing capacity of the surface the vacuum cleaner
is placed on must be suitable for bearing its weight).
Vacuum Cleaner Parts and Labels
Figure 1
1. Identication plate which includes:
Code of the Model, Class, Technical Specications
(see table on page 6), Serial N°, EC Mark, Year of
manufacture, Nominal network voltage.
2. Dust bag
3. Inlet
4. Inlet plug
5. Machine release hooks
6. Machine lifting/lowering handles
7. Outlet
8. Castor lever
9. Handle
10. Closing band lever
11. Safety bolt
12. Filtration class label
13. Attention plate
Draws the operator's attention to the fact that the lter
must only be shaken when the vacuum cleaner is turned
OFF (see also par. "Primary lter shaker").
14. Plug for connecting the vacuum cleaner to an electrical
socket.
Figure 2
1. Class H label
2. Class M label
The class H label reads the following.
WARNING!
This vacuum cleaner contains dust
hazardous for the health.
Only authorised personnel wearing
suitable personal protective equipment
should empty and service the vacuum
cleaner, including removing the means used to
vacuum the dust. Do not use without the complete
lter system in place.
This vacuum cleaner creates a strong air ow, which is
drawn in through the inlet (3 - Fig. 1) and blown out through
the outlet (7 - Fig. 1).
Before turning on the vacuum cleaner, t the vacuum hose
into the inlet and then t the required tool on to the end part
(refer to the manufacturer's accessory catalogue or Service
Centre).
The diameters of the authorized hoses are indicated in the
Technical data table.
The vacuum cleaner is equipped with a main lter which
enables it to be used for the majority of applications.
Besides the primary lter, which retains the most common
types of dust, the vacuum cleaner can be tted with a
secondary lter (absolute class H) with a higher ltering
capacity for ne dusts and dusts that are hazardous to
health.
