Operating manual BDC-133M / BDC-133H
GB
Technical data
EU UK
Parameter Units BDC-133M BDC-133M
Voltage (50 - 60 Hz) V 230 110 230
Power rating kW 3 3
Power rating (EN 60335-2-69) kW 2.6 2.2 2.6
Max vacuum hPa-mbar 211 165 211
Maximum air ow rate (with hose, length: 3 m,
diameter: 50 mm)
L/min' 6500 5950 6500
Noise level (Lpf) (EN60335-2-69) dB(A) 71 71
Protection IP 44 44
Insulation Class GB GB
Longopac
®
dust bag capacity L 25 25
Inlet (diameter) mm 70 70
Allowed hoses mm 51-76 51-76
Main lter surface m
2
1.95 1.95
Upstream absolute lter surface m
2
3.5 3.5
Absolute lter eciency (EN 1822) % 99.995 (H14) 99.995 (H14)
Weight kg 73 73
Dimensions
Figure 4
Model BDC-133M
A (mm) 800
B (mm) 600
C (mm) 1300
(1) Net weight Storage conditions:
T: -10°C ÷ +40°C
Humidity: 85%
Operating conditions:
Maximum altitude: 800 m
(Up to 2,000 m with reduced
performances)
T: -10°C ÷ +40°C
Humidity: 85%
