Blastrac BDC-66 - Page 33

Page
BDC-66 UL
Ed.
4
PJ13.1140.03
HvdB +
Date
Date
Panel Layout
1
Modification
0 76
Appr
8 93
6
4
17-7-2014
5
2
=
Name
5
Blastrac bv
Customer:
Drawing number:
Page description:Project name:
© ART4 Technical Systems, Soest NL
17-7-2014
Last print
E09229
CABINET
FRONT VIEW
MOUNTING PLATE
CABINET DATA
SCHNEIDER
NSYS3D64020P
(HxBxD) 600x400x200
13S1
CABINET
BOTTOM VIEW
CABINET
LEFT HAND VIEW
10QM1
Axle lenght 95mm
M16 for PE to Frame
600 mm
400 mm
355 mm
555 mm
22,5 mm
22,5 mm
ø 10 mm
Place 4x blind rivets M8
10X2
13H2
13H1
13H3
13SH1
13SH2
14U1
10Q1
10Q2
10S1
11F1
11T1
13KM2
13KM1
10F1
40x60
40x60
25x60
11K3
25x60
10QM1
25x60
X1 X2
10F2
1 L1
3 L2
5 L3
2 T1
4 T2
6 T3
I
T
O
4.0A
2.5
1 L1
3 L2
5 L3
2 T1
4 T2
6 T3
I
T
O
4.0A
2.5
13P1
11F2
(*): With cable
M16 - Pulse system 3x0.75mm² length 3,0 mtr.
M20 - Compressor
M32 - Fan
M50 - Power supply
10X2
20
16 16
1616
16
50
32
CAB
