Blastrac BDC-66 - Page 43

Page
BDC-66 UL
Ed.
30
PJ13.1140.03
HvdB +
Date
Date
Part list
1
Modification
0 76
Appr
8 93 4
16-7-2014
31
2
=
Name
5
Blastrac bv
Customer:
Drawing number:
Page description:Project name:
© ART4 Technical Systems, Soest NL
17-7-2014
Last print
E09229
Type number
Brand
Parts list
Quantity designationdevice tag Blastrac number
194E-A100-1753 Allen Bradley E0795710QM1 3P 100A, dinr.mot UL489
1
194L-HE6I-175 Allen Bradley E0795810QM1 Bed. draaisch. rood/geel voor 194L-E (64*64) UL489
1
194L-G3393 Allen Bradley E0838210QM1 Operating shaft
1
194E-A100-3753 Allen Bradley E0796010S1 Faseomkeerschakelaar 6P 100A, bodem montage omkeerbaar UL489
1
194L-HE6A-375 Allen Bradley E0795910S1 Bed. draaisch. grijs/zwart voor 194L-E (64*64) UL489
1
ZB4-BS844 Schneider Electric E0843713S1 Red Ø40 Emergency switching off pushbutton head Ø22 latching
1
ZB4-BZ104 Schneider Electric E0133313S1 Body for control button - Ø 22 - 2NC
1
ZBY-9330 Schneider Electric E0036113S1 Marked legend 60 for emergency stop - EMERGENCY STOP/logo I
1
ZB5-AVB3 Schneider Electric 333-349613SH1 Green light block with body/fixing collar integral LED 24V
1
ZB5-AW7A3741 Schneider Electric E0780413SH1 Green flush/red flush illuminated double-headed pushbutton Ø
1
ZBA-710 Schneider Electric E0507013SH1 Transparent boot for rectangular multiple-headed pushbutton
1
ZBE-101 Schneider Electric E0509113SH1 Single contact block for head Ø22 1NO screw clamp terminal
1
ZBE-102 Schneider Electric E0509213SH1 Single contact block for head Ø22 1NC screw clamp terminal
1
ZB5-AVB3 Schneider Electric 333-349613SH2 Green light block with body/fixing collar integral LED 24V
1
ZB5-AW7A3741 Schneider Electric E0780413SH2 Green flush/red flush illuminated double-headed pushbutton Ø
1
ZBA-710 Schneider Electric13SH2 Transparent boot for rectangular multiple-headed pushbutton
1
ZBE-101 Schneider Electric13SH2 Single contact block for head Ø22 1NO screw clamp terminal
1
ZBE-102 Schneider Electric13SH2 Single contact block for head Ø22 1NC screw clamp terminal
1
SIEM 4AM4342-8DN00-0EA0 Siemens11T1 Transformer Sitas 315VA 480V 550..208V/24V UL/CSA
1
SR2B121B Schneider Electric14U1 Compact smart relay Zelio Logic - 12 I O - 24 V AC - clock -
1
SR2MEM02 Schneider Electric14U1 Memory cartridge - for smart relay Zelio Logic firmware - fo
1
WEID ZDU 4 WeidmullerX1 Tension clamp terminal 2*4(6)mm
3
WEID ZPE 4 WeidmullerX1 Earth terminal for ZDU 4 2*4(6)mm
2
EINDSTEUN V4 CON.ACC Wieland E07828X1 Eindsteun V4 klein 9708/2S35
2
WEID ZAP/TW 1 WeidmullerX1 End plate Beige for ZDU 2.5
1
WEID ZDU 2.5 WeidmullerX1 Tension clamp terminal 2*2.5 beige
3
WEID ZPE 2.5 WeidmullerX1 Earth terminal for ZDU 2.5 2*2.5(4)mm
1
WEID ZAP/TW 4 DB WeidmullerX1 End plate Beige for ZDU 4
1
WEID ZDK 2.5 Weidmuller E05169X2 tension clamp terminal multi level 2*2.5
3
E05070
E05091
E05092
E08128
E05168
E05167
E08171
E08172
E05166
WEID ZDK 2.5PE Weidmuller E05170X2 Earth terminal for ZDK 2*2.5
2
569419 Walther10X2 Walther UL receptical CEE 4x60A 480V
1
E08409
E08410
E08411
E08441
