BDC-66 UL
Ed.
13
PJ13.1140.03
HvdB +
Date
Date
Control Current Zelio PLC
1
Modification
0 76
Appr
8 93
20
4
16-7-2014
14
2
=
Name
5
Blastrac bv
Customer:
Drawing number:
Page description:Project name:
© ART4 Technical Systems, Soest NL
17-7-2014
Last print
E09229
Air Pulse system Spare
I1 = start signal
I2, I3, I4 = spare start signal
I5 = Timer setting (when not connected than in UL mode)
I6 = Spare timer setting
I7 = 2 pulses for 2 valves system (when not connected 3 valves system)
I8 = spare pulse setting
14U1
Schneider
ZELIO
12 I/O
SR2B121B
L1
N 1
Q1
2 1
Q2
2 1
Q3
2 1
Q4
2
I1 I2 I3 I4 I5 I6 I7 I8
X1
X2
Y1
X1
X2
Y2
1
X2
2 PE3 4
90
90
105
90
110 111
83 8383
PE5 6
105
24VAC-A
/13.9
24VAC-B
/13.9
14U1.I1
/13.7
