Blastrac BDC-66 - Page 50

Page
BDC-66 DUAL VOLTAGE ULCSA
Ed.
5
PJ11.1068.22
HvdB +
Date
Date
Cable set
1
Modification
0 76
Appr
8 93
10
4
13-3-2014
8
2
=
Name
5
Blastrac bv
Customer:
Drawing number:
Page description:Project name:
© ART4 Technical Systems, Soest NL
20-12-2016
Last print
E09226/230ULCSA
COMPRESSOR
U1/16
36/1
37/2
38/3
39/4
40/5
42/6
31/7
33/8
35/9
41= gn/ye
Wires for compressor
9x AWG 18 UL Black 1250mm
1x AWG 18 UL gr/ye 1250mm
80 mm3000 mm200mm
3280 mm
SP16-M20B
36/1
37/2
38/3
39/4
40/5
42/6
31/7
33/8
35/9
41= gn/yl
PVC 7xAWG 14
750 mm
250 mm 250 mm
1250 mm
V1/20
W1/24
W2/25
U2/17
V2/21
PE
(1)
(2)
(3)
(4)
(5)
(6)
(pe)
CABINET
SP16-M20/A
Slang SP16
V1/20
W1/24
U2/17
V2/21
W2/25
PE
(1)
(2)
(3)
(4)
(5)
(6)
(pe)
U1/16
TO FAN MOTOR
TERMINALS
CABINET
M5 blue
PE
850 mm
Ground Wire for connection to machine frame
AWG 8 Green/yellow
Connect to inside cabinet wall
M8
Speciale type
