Operating Instructions EBE 350 E
Spare parts
Drive system
Item Part no. Description Qty.
1 500-3011-E Drive motor 2
2 500-1125-E Drive motor shaft 2
3 222-2810-VH Drive motor sprocket 2
4 350-9129-E Drive motor plate outer left 1
5 350-9131-E Drive motor plate inner left 1
6 350-9130-E Drive motor plate outer right 1
7 350-9132-E Drive motor plate inner right 1
8 350-2185-E Drive wheel 2
9 500-1135-E Bearing flange drive wheel shaft 4
10 222-2331-E Drive wheel bearing 4
11 500-1130-E Drive wheel shaft 2
12 222-2525-VH Drive wheel sprocket 2
13 222-2285-V Taperlock bush 2
14 350-2213-E Drive motor chain 2
15 350-9105-E Rear wheel drive chain guard 2
10
