Blastrac EBE 350 E - Unit Specifications

Operating Instructions EBE 350 E
Technical data
1.1 Rating
Unit / designation : ISPC Blastrac/EBE blast cleaning
machine
Machine type : EBE 350 E
Manufacturer : ISPC Blastrac/EBE
Utrechthaven 12
NL-3433PN Nieuwegein
THE NETHERLANDS
1.2 Unit specifications
Dimensions:
Machine
EBE 350 E
Length 1350 mm
Width 650 mm
Height 1100 mm
Weight 375 kg
Connected loads (electrical system):
The indicated input current values correspond to the nominal current
values of the motors working under full load. These values are not
achieved under normal operating conditions.
Power consumption Input current
EBE 350 E Blast
wheel drive
11.0 / 13.0 kW max. 20 A
Fan motor 1.5 / 1.8 kW max. 3.5 A
Drive motors 0.37 kW max. 1.78 A
Electrical connection required : 400-480 V, 50/60 Hz, 32 A
2
