Blastrac EBE 350 E - Page 79

Change
11
0
Date Name
Start
Eng.
Print
Status
1
14.03.2000
RJO
11.02.2002
As build
USF EBE B.V.
Blastmachine EBE 350
S/E UniversalC
2 3
4
Frontview
5 6
Arch.nr.
Draw.nr.
PJ00.01027__A
7 8
Pages
=
+
13
Page
9
13
12
Frontview
1
10
4
7
11
13
5
8
12
14
3
6
9
2
1:
2:
3:
4:
5:
6:
7:
8:
9:
10:
11:
12:
13:
14:
5P1
4Q1
6H1
6H2
6H3
6H4
6S2
6S4
6S7
6S3
6S5
6S6
6S1
6P1
Ammeter
Main switch
Control Voltage
Drive
Fan
Main Blast
Start Drive
Start Fan
Start Main Blast
Stop Drive
Stop Fan
Stop Main Blast
Emergency Stop
Operating Time Counter
