7
The fan is equipped with a removable grille.
To release the grille from the face cover press the latches gently.
During mounting of the grille on the face cover back match the latches and corresponding
slots in the cover and insert to click. The arrow on the grille back side must be directed
to the shorter side close to the hole.
The fan casing has three round lowered tabs for cable entry.
Cut out a hole at the most suitable place with a knife.
8 9
10
