NAME OF EACH PART AND FUNCTION
FRONT (Fig. 1)
1. Control panel
2. Up/down manually adjusted air fins
3. Air outlet
4. Left/Right auto air swinging fans
5. Rolling castor
6. Cable (power cord and plug)
BACK (Fig. 2)
1. Hot air outlet grill
2. Low air inlet grill
3. High air inlet grill
4. Power cord hooks
5. Water tank/chassis
6. Water tank drain outlet
7. Plug
Fig. 1
Fig. 2
