Blaupunkt BAC28WC - Product Overview

7
PRODUCT OVERVIEW
1. MIN/TUNING+ button
2. HOUR/TUNING- button
3. SET TIME/PRESET button
4. SLEEP/SCAN button
5. AL1/VOLUME - button
6. AL2/VOLUME + button
7. POWER/SOURCE button
8. PLAY/PAUSE button
9. SNOOZE/BRIGHTNESS button
10. BT PAIRING button
11. MICROPHONE
12. DISPLAY
13. AUDIO IN
14. USB (CHARGE SOCKET)
15. USB (CHARGE SOCKET)
16. DC JACK
17. WIRELESS CHARGING LOCATION
17
11
5
6
7
8
1
2
3
4
9
12 13 14 15 16
10
US B 5V US B 5V
DC 9 V
AU X
