Press the MENU button to store the set
value and to switch to the next menu
item.
If none of the monitor buttons are
pressed for approx. 8 seconds, the
menu is closed and all the set values
are stored.
Settings in TravelPilot mode
➮ On the CCU01, switch to
TravelPilot. The settings are
changed in the same way as in
video mode.
Day/night setting
If the vehicle lights are turned on, the
monitor’s brightness will switch to night
mode. For this feature to work, the
monitor’s DIM display connection (Plug
III/Pin 3) must be connected to the + of
terminal 58.
The brightness and contrast picture set-
tings can each be adjusted
separately
for day and night and for video mode
and TravelPilot mode. The set values
are stored when the menu is closed.
System settings
➮ Keep pressing the MENU button
on the CLX01 until SYSTEM +>>>
appears in the display.
➮ Next, press the button.
The following appears in the
display
CAM1+CAM2+CAM3
CAMERA SETUP
CONTROLS AND SETTINGS
Subject to changes!
➮ Press the or button to select
the required camera configuration.
Note:
Only the selected cameras can be
switched on.
To select the reversing camera
➮ press the MENU button to access
REAR VIEW CAMERA mode.
➮ Press the or button to select
INVERTED, if you want to display
a mirror image of the reversing
camera signal or
NORMAL for a non-mirror image.
When you close the menu, any changes
that you made to the settings will be
stored.
Specifications
Operating voltage: 12 V - 24 V
Closed-circuit current: 30 mA
Stand-by current: < 1 mA
Output voltage
for cameras: 12 V / 200 mA
