INSTALLATION & WIRING DIAGRAM
4
REM-OUT to car radio
+BATT +12V
-BATT
Use 1mm (16AWG)
cable for power supply
connection
T30A-delayed
(fuse & holder are
not provided)
Remark : The device is protected by its built-in fuse-resistor
Ground
Ground
12V
