BLH NOBEL G4-HE - Page 50

Technical Manual
3-14
Range/Alternatives Explanation and
<default value> result of alternatives.
Slot 2 Module Type
< No module > This parameter defines what type of I/O- module is
installed in slot 2. See ‘Slot 1 Module type’ for details on
parameter values.
Slot 2, ch 1 Scale no
<Not in use> This parameter defines which scale (1 – 8) that
channel 1 in slot 2 will be connected to. Each scale may
only be assigned once.
Note: this parameter is only shown if ‘Slot 2 Module type’
is set to ‘WFIN’, ‘WFIN2’ or ‘HSWF2’.
Slot 2, ch 2 Scale no
<Not in use> This parameter defines which scale (1 – 8) that
channel 2 in slot 2 will be connected to. Each scale may
only be assigned once.
Note: this parameter is only shown if ‘Slot 2 Module type’
is set to ‘WFIN2’ or ‘HSWF2’.
Slot 3 Module Type
< No module > This parameter defines what type of I/O- module is
installed in slot 3. See ‘Slot 1 Module type’ for details on
parameter values.
Slot 3, ch 1 Scale no
<Not in use> This parameter defines which scale (1 – 8) that
channel 1 in slot 3 will be connected to. Each scale may
only be assigned once.
Note: this parameter is only shown if ‘Slot 3 Module type’
is set to ‘WFIN’, ‘WFIN2’ or ‘HSWF2’.
Slot 3, ch 2 Scale no
<Not in use> This parameter defines which scale (1 – 8) that
channel 2 in slot 3 will be connected to. Each scale may
only be assigned once.
Note: this parameter is only shown if ‘Slot 3 Module type’
is set to ‘WFIN2’ or ‘HSWF2’.
Slot 4 Module Type
< No module > This parameter defines what type of I/O- module is
installed in slot 4. See ‘Slot 1 Module type’ for details on
parameter values.
Slot 4, ch 1 Scale no
<Not in use> This parameter defines which scale (1 – 8) that
channel 1 in slot 4 will be connected to. Each scale may
only be assigned once.
Note: this parameter is only shown if ‘Slot 4 Module type’
is set to ‘WFIN’, ‘WFIN2’ or ‘HSWF2’.
