G4 Multi Channel Weighing Instrument
3-13
Range/Alternatives Explanation and
<default value> result of alternatives.
Menu ‘Hardware config.’
Fieldbus
Not In Use
Profibus
DeviceNet
<Not In Use>
This parameter defines what type of fieldbus that will be
used in the CPU.
Not In Use: The fieldbus is not used regardless of any
installed module.
Profibus: A Profibus type of fieldbus module is used.
DeviceNet: A DeviceNet type of fieldbus module is
used.
Slot 1 Module Type
No module
HSWF2
WFIN
WFIN2
AOUT1
AOUT4
DIO8
<WFIN2>
This parameter defines what type of I/O-module that will
be used in slot 1.
No module: No module is used in this slot.
HSWF2: A 2 channel high speed weight/force module.
WFIN: A 1 channel, weight/force measuring module.
WFIN2: A 2 channel, weight/force measuring module.
AOUT1: A 1 channel analog output module.
AOUT4: A 4 channel analog output module.
DIO8: A 8/8 digital input/output module.
Slot 1, ch 1 Scale no
Not in use
1
2
3
4
5
6
7
8
<1>
This parameter defines which scale (1 – 8) that
channel 1 in slot 1 will be connected to. Each scale may
only be assigned once.
1: This slot and channel is assigned to scale no 1.
2: This slot and channel is assigned to scale no 2.
….
8: This slot and channel is assigned to scale no 8.
Not in use: This slot and channel is not assigned to any
scale.
is set to ‘WFIN’, ‘WFIN2’ or ‘HSWF2’.
Slot 1, ch 2 Scale no
<2> This parameter defines which scale (1 – 8) that
channel 2 in slot 1 will be connected to. Each scale may
only be assigned once.
