Blitz SBC i-D - Main Menu; Boost; Scramble; Speed Map

MAIN MENU
BOOST
Boost Controller settings
1 To get to Main Menu, press Menu button. To set, refer to Page 6
2 Turn the knob to scroll for desired options.
WARNING
Warning and limiter settings
To set, refer to Page 7
MAIN MENU
SCRAMBLE
Scramble boost settings
1. Go to Main Menu and select the To set, refer to Page 7
BOOST display desired.
SPEED MAP
Speed Map is only used with the Blitz Power Meter I-D
WARNING To set, refer to Page 8
SCRAMBLE
DISPLAY
Different displays (up to 6)
SPEED MAP Refer to Page 8
DISPLAY
REPLAY
Record and replay
REPLAY
To use, please refer to Page
DATA
Optional features
Refer to Page 9
MAIN MENU
AUTO PEAK
Automatic Peak hold reset.
2. How to set To set, refer to Page 9
REPLAY Press enter to select.
AC / WG
Actuator / Wastegate settings
DATA To set, refer to Page 9
AUTO PEAK OFF
UNIT
Boost type kg/cm2, kpa, bar and PSI
AC / WG AC To set, refer to Page 9
UNIT PSI
CONTRAST
Adjust the contrast of the display unit (0~100)
CONTRAST
35
To set, refer to Page 9
BRIGHT
Adjust the brightness of the display unit (0~10)
To set, refer to Page 9
MAIN MENU
RESET
Erase and resets the boost controller
3. How to unselect To set, refer to Page 9
AUTO PEAK OFF If you press the menu button at any
AC / WG AC time, the previous screen will
UNIT PSI appear.
CONTRAST
35
BRIGHT 15
RESET
Page 5
