Blitz SBC i-D - Display Menu; How to Set Speed Map

SPEED MAP DISPLAY MENU
- The Speed Map allows the user to set boost pressure according - SBC I-D has the ability to display different options. It has the
speed of the vehicle. ability to display 6 different options (Boost, OPTN 1~2, DATA 1~3).
- The Speed Map option will only work if the Blitz Power Meter I-D Each option also can be display is both graphical and digital
is hooked up, otherwise the SBC I-D display will show form. Power Meter I-D and option SBC I-D harness is needed
NO CONNECT. to display other 5 options (OPTN 1~2, DATA 1~3).
SBC I-D
WITHOUT
SBC I-D
WITH
DISPLAY MENU
Power Meter I-D
Power Meter I-D
SPEED MAP SPEED MAP BOOST DIGITAL BOOST Boost in digital display
MPH GRAPH BOOST Boost in graph display
CH 1 III OPTN1 DIGITAL OPTN 1 Option 1 in digital display
NO CONNECT. CH 2 III GRAPH OPTN 1 Option 1 in graph display
CH 3 III OPTN2 DIGITAL OPTN 2 Option 2 in digital display
CH 4 IIII
GRAPH
OPTN 2
Option 2 in graph display
OFF . . . . IIII
0 100 200
DISPLAY MENU
Note:
For Speed Map to display MPH settings, you must change DATA 1 DIGITAL DATA 1 DATA 1 in digital display
SBC I-D Unit setting to PSI. GRAPH DATA 1 DATA 1 in graph display
Explanation of Speed Map Diagram
DATA 2 DIGITAL DATA 2 DATA 2 in digital display
- The Diagram above shows that the vehicle from 0-50 mph GRAPH DATA 2 DATA 2 in graph display
will be in Channel 1, then the boost controller will automatically DATA 3 DIGITAL DATA 3 DATA 3 in digital display
change to Channel 2 from 50-75 mph and continue on until it
GRAPH
DATA 3
DATA 3 in graph display
reaches Channel 4.
- Speed Map can also work with 2 Channels, not all 4 Channels
have to be used. To turn off Speed Map set all tabs to off
NOTE:
If Power Meter I-D is connected, both OPTNs in Display
positions located under Channel 4. Menu will change. OPTN 1 will be replace by SPEED, and OPNT2
will be replace by POWER.
How to Set Speed Map
1
Set up Boost Channels as desired. DISPLAY MENU
SBC I-D with
2
Go to Speed Map option located in Main Menu.
Power Meter I-D
3
Press enter to set, scroll left or right and set tabs BOOST DIGITAL
according to your desire. Press enter to set. GRAPH
Repeat until Speed Map is set. SPEED DIGITAL
Important:
Speed Map will be activated once any tabs are GRAPH
set. Make sure all tabs are set on the off position is Speed POWER DIGITAL
Map is not used.
GRAPH
Page 8
