Blitz VERSA Series - 1 Fundamental Safety Instructions; Table of Contents; Description of Symbols and Notes; Designated Use

3102619 03/13
Operating Instruction
Index
1 Fundamental safety instruc-
tions
1.1 Designateduse
Thecompressorsystemisintendedexclusively
forthegenerationofcompressedair.Anyother
useshallbeconsideredanundesignateduse.
1.2 Fundamentalmeasures
• Neverpointcompressedairatpersons.
• Observetheseoperatinginstructions.
• Keeptheseoperatinginstructionsavailable
atthelocationofuseatalltimes.
• Observetheregularmaintenancedead-
lines(cf.chapter6“Maintenanceplan”).
• UseoriginalBLITZpartsandapproved
operatingmaterialonly.
• Donotusecompressedairforbreathing
withoutcorrespondingtreatment.
• Donotmodifythesystem.
• Usemountingpartsanddevices
downstreamfromthecompressorwhich
havebeendesignedforthemaximumope-
ratingoverpressureofthecompressor.
• Inyourcapacityasproprietor,pleaseensu-
rethatallsafetyregulationsareobserved
bytheoperatingstaff.
• Donotusethecompressorasaclimbing
aid.
1.3 Descriptionofsymbolsandno-
tes
Danger
Mortaldangerandriskofinjury.
Caution
Damagetoproperty..
Informationandtips.
Index
1 Fundamental safety instructions ..... 3
1.1 Designateduse ................................... 3
1.2 Fundamentalmeasures ...................... 3
1.3 Descriptionofsymbolsandnotes ....... 3
2 Transport and storage ...................... 4
2.1 Transport ............................................. 4
2.2 Storage ................................................ 4
3 Mounting ............................................ 4
3.1 Mountingconditions ............................ 4
3.2 Compressed-airport ........................... 5
3.3 Electricalconnection ........................... 5
4 Operation ........................................... 7
4.1 Safetyinstructions ............................... 7
4.2 Switching the unit on ........................... 7
4.3 Dailycheck-ups ................................... 7
4.4 Switchingtheunitoff ........................... 7
4.5 OriginalBLITZaccessories ................. 7
5 Inspection and servicing .................. 8
5.1 Safetyinstructions ............................... 8
5.2 Checkingandtoppinguptheoillevel . 8
5.3 Changingtheoil .................................. 9
5.4 Drainingthecondensationwater ......... 9
5.5 Checkingandchangingthe
 suctionltercartridge .......................... 9
5.6 Tighten the screw connections. ........... 9
6 Maintenance schedule .................... 10
7 Trouble shooting ..............................11
Technical annex
