Blomberg DWT25504SS - Steam Protection Foil

14
USA
6.7 STEAM PROTECTION FOIL
Steam will form inside the dishwasher during operation. At the end of the cycle, when the
dishwasher door is opened, it is required to use a 󰀬eam protection foil to prevent any
󰀬eam from collecting on the underside of the counter top.
6.6.2 FITTING THE PROTECTION FOIL
Before applying the 󰀬eam protection foil to the
underside of the countertop, clean the area with
a damp cloth (as shown in Figure A). Once the
area dries, apply the 󰀬eam protection foil.
CAUTION
Steam protection foil mu󰀬 be applied
where the 󰀬eam escapes when door is
r󰀬 opened. Failure to in󰀬all the 󰀬eam
protection foil during in󰀬allation can
lead to damage to the cabinets and
countertop.
The 󰀬eam protection
foil will be applied at the
location where the hot
󰀬eam escapes when you
r󰀬 open the door (as
shown in Figure B).


