7.5 PREPARING THE TIMBER DOOR
X =
?
X
=
=
Mid. Point
=
=
Mid. Point
Height (h) : Height of the wooden door 30” (760mm) Tall Tub Models Only
Height (h) : Height of the wooden door 28” (720mm) Standart Tub Models Only
Width (w) : 23 ¼” to 23 ½” (592mm - 595mm)
Thickness (t) : ¾ “ (19mm)
Weight (max) : 9 Kg / 19 lbs
Weight (max)
9 Kg / 19 lbs
o) s)
n)
t)
