19
USA
B
C
8
11
/
16

(
221
,
2
mm)
221,2mm
Mid. Point
2. Remove the plastic mounting brackets from
the dishwasher (Figure B).
D
D
3. Lay the schematic over the door
from the bottom up and mark holes
on the wooden door as shown in the
drawing (Figure C).
4. Place the plastic mounting brackets over the
marked holes and the side tabs must be flush
with the edge of the wooden door (Figure D).
