Blomberg DWT37300 - Page 24

21
USA
y
x4
A
Ø
3
/
16
" (4mm)
B
y
x4
C
Ø
3
/
16
" (4mm)
8. Using the four screws Ø
3
/
16
” x 1
11
/
16
” (Ø
4mm x 43mm) provided, attach the wooden door
to the dishwasher at position 1 and 4 (Figure A).
9. Check the position of the wooden door and
make sure it is aligned properly (Figure B).
10. Tighten the screws in position 1 and 4
completely after the final alignment (Figure C).
