- 12 -
CIP Valve Installation (Optional)
Two optional shut-off valves can be used to isolate the BLOOM from the rest of the system
for Clean in Place maintenance. See Table 4 for CIP valve sizes recommendations.
Connect Power to Control Box.
WARNING: Before connecting power, verify the voltage, phase and amps
requirements of your BLOOM. See purchase order for unit details.
All BLOOMS are single-phase model, there will be two wires coming out of the overload relay,
as shown in the red circle photo 1. Photo 2 shows the ground connection.
Photo 1. Output Terminal Connections on Photo 2. Ground
Overload Relay Wired for a Single Phase.
WARNING: Ensure that the ground wire from the power cable is connected to the
grounding bar inside the enclosure.
