Blue Diamond Post Driver - Specifications

9
Specifications
A B
C
Post Driver
Post Driver
w/ Grapple
Post Driver
w/ Tilt
Post Driver
w/ Tilt &
Grapple
Overall Width (A) 45.5"
Overall Length (B) 25" 25.5"
Overall Height (C) 64"
Tilt (left or right) N/A 20°
Weight 300 lbs. (500 lbs. max.)
Length of Stroke 40"
Max. Strokes Per Minute 35
Hydraulic Requirements
1500-3000 PSI
Up to 30 GPM
Maximum Post Size 8.5" x 9.25"
Impact Force 82000 lbs. @ 500 lb. weight
Impact Energy 1025 ft.-lbs. @ 300 lb. weight; 1709 ft.-lbs. @ 500 lb. weight
Hitch Skid-Steer Quick Attach
Operator's Manual
Direction Terminology
Front
Rear
Left
Right
100100
100105
100110
100120
