Changing System Labels
The M2 allows the user to change the labels that are displayed above each channel. Each channel can have a maximum of 16 characters however in
the summary screens only the rst 11 or 12 characters of the channel label are displayed.
Changing Label Names
To change the name of a tank, follow the instructions below:
1. Navigate to the setup menu for the desired tank (such as tank Setup). Menu->Setup->Tank 1 Setup
2. In the menu, move the cursor to tank name to be changed (indicated by the >> symbol)
3. Press Select to enter the name editing mode.
4. Use the LEFT ← and RIGHT → arrow buttons to move the cursor over the characters.
5. When the cursor is over a character, press Enter to edit that character. The cursor will start blinking.
6. Use the UP ↑ and DOWN ↓ arrow buttons to select a new character and press Ok to set that character.
7. Once all desired characters have been changed, press the Cancel button to exit the name editing mode.
Note: Although the maximum label length is 14 characters, some screens may only be able to display the rst 5 or so characters.
Tank Setup
The meter provides setup settings for each tank. To access these settings, rst go to the Setup menu. Scroll to the desired tank.
The tank setup settings are described below. To make a change, scroll to setting and press Enter. Press the LEFT ← or RIGHT → arrow buttons to view
the available setting options. Press Enter to save the setting. Press Cancel to cancel a change.
Enable
To display the tank and its measurements, change this setting to ON. If enable is OFF, the tank along with its measured values will not be displayed.
However, any associated alarm or relay settings are still activate. To de-active the alarm or relay, disable them in the Alarm Setup and Relay Setup menus.
Volume
To display the tank and its measurements, change this setting to ON. If enable is OFF, the tank along with its measured values will not be displayed.
However, any associated alarm or relay settings are still activate. To de-active the alarm or relay, disable them in the Alarm Setup and Relay Setup menus.
Show Percent
If this value is on, then tank values will displayed as a percentage. If the value is off then it will be displayed in either gallons or liters.
Sender Type
This setting presets the Resistance Lo and Resistance Hi values based on the type of sender attached to the meter. The available options are listed below:
• USA– North American Standard type of sender between with a resistance between 240 and 33 ohms.
• Euro – European Standard type of sender with a resistance between 10 and 180 ohms
• 1810 – Blue Sea Systems Ultrasonic Tank Sender for Diesel, Water & Waste.
• 1811 – Blue Sea Systems Ultrasonic Tank Sender for Gasoline Only
• Cstm – Indicates the Resistance Lo or Resistance Hi value has been manually changed.
Resistance Lo/Resistance Hi
The tank meter operates by reading the resistance of the tank sender. The resistance value (in ohms) can be entered here for an empty tank
(Resistance Lo) and for a full tank (Resistance Hi). Changing either of these values when the Sender Type is set to either 1810 or 1811 will give
unpredictable results when an Ultrasonic Tank Sender is used.
