BLUELIGHT BL6-U User Manual

BL6-U Parallel Integrated Controller Quick Commissioning User Manual
1
1 BL6-U Parallel Integrated Controller Model & Specifications
1.1 Model description
Model description of BL6-U Parallel Integrated Controller is shown as figure 1(take 22KW closed
type controller as example).
Specifications list in chart 1.
BL6 － U O 4 0 2 2 － B
Controller series
Additional Type
None: Serial integrated
controller (with glass shell
or no shell)
W: with metal shell
B: parallel
C: Ultra-thin without shell
S: Small size
H: For home lift
N: Plastic shell
M: Modularization
Controller type
U: Elevator in-built controller
S: High performance inverter
Maximum
machine power
005:5.5KW
007:7.5KW
011:11KW
015:15KW
018:18.5KW
022:22KW
030:30KW
037:37KW
045:45KW
055:55KW
075:75KW
Protective structure
C: Closed type
O: Open type
Voltage level
4:380V
2:220V
FIGURE 1.1 MODEL DESCRIPTION DIAGRAM

BLUELIGHT BL6-U Specifications

General

Brand	BLUELIGHT
Model	BL6-U
Category	Controller
Language	English
