8 Hoistway Parameter Learning
Chart 8.1 Parameters need to set before hoistway parameter learning
Para No.
Name
Setup Method
F0-00
Total Floor
Set floor number based on actual site condition.
8.1 Perform Hoistway Parameter Learning with Digital Operator
Hoistway parameter self-learning means elevator runs at a self-learning speed and measures
every floor height and record the position of every switch in the hoistway. As the floor position is the
foundation for elevator normal running, braking and floor display. Therefore, before normal running,
hoistway parameter self-learning must be performed. Before hoistway parameter self-learning,
inspection running in full trip must be performed too; elevator must be able to run normally from
bottom limit to top limit.
Hoistway parameter self-learning procedure is as follows:
1) Make sure elevator meets the conditions for safety running!
2) Make sure all the switches in hoistway are installed and connected correctly, traveling cable
and hoistway cable are connected correctly, and finish setting the HOP/display address;
3) Elevator in inspection mode, jog elevator down to the down limit (down limit is valid);
4) Enter elevator hoistway self-learning menu through digital operator, follow the learning
procedures shown below in Figure 8.1.
Hoistway Learn
Floor: 5
To DownLimit
Hoistway Learn
Floor: 1
[ENTER] to start
Hoistway Learn
Floor: 1
Waiting
Hoistway Learn
Floor: 6
Success
Hoistway Learn
Floor: 6
ERR 01
[ENTER]
Figure 8.1 Hoistway Parameter Self-Learning Procedures
5) The results of learning can be seen from hoistway position parameter U0-00 to U0-69 under
monitor menu with unit of meter, please check the switches position after hoistway learning.
6) In self-learning process, if control system detects any abnormal phenomenon, self-learning
will be terminated and give fault code, please refer to troubleshooting table in chapter 8, find out the
reason and solve it accordingly, then start hoistway parameter self-learning again.
Note: When self-learning process stops, only when LCD indicator shows “success” on digital
operator, self-learning is completed successfully.
