BLUELIGHT BL6-U User Manual

BL6-U Parallel Integrated Controller Quick Commissioning User Manual
3
CHART 1.1 SPECIFICATIONS 
D
RIVE CONTROL
FEATURES
MAIN CONTROL FUNCTIONS
START WITHOUT LOAD COMPENSATION, BATTERY OPERATION, AUTO TUNING,
LOAD COMPENSATION, COOLING FAN CONTROL, BASE BLOCK, TORQUE LIMIT,
CAN COMMUNICATION REF, ACCELERATION/DECELERATION TIME, S CURVE
ACCELERATION/DECELERATION, MONITOR OF MAIN MACHINE FOR WHICH
ELECTRIC CURRENT CAN BE EFFECTIVELY INTERDICT OR NOT WHEN THE CAR
STOPS; INTERNAL BRAKE, PG FREQ DIVIDING OUTPUT, AUTOMATIC FAULT RETRY,
AUTOMATIC FAULT RESET, PARAMETER COPY
C
ONTROL
/I
NPUT
/
O
UTPUT INTERFACE
OC INPUT CONTROL POWER
ISOLATED EXTERNAL DC24V
RELAY OUTPUT CONTROL POWER
ISOLATED INTERNAL DC24V
LOW OPTO-ISOLATED INPUTS
46-CHANNEL SWITCHES: RATED LOAD 7MA/DC24V, UPPER FREQ 100HZ
HIGH OPTO-ISOLATED INPUTS
2-CHANNEL SWITCHES: RATED LOAD 8MA/AC110V, UPPER FREQ 100HZ
PROGRAMMABLE RELAY OUTPUT
24-CHANNEL SWITCHES:1NO, CONTACT CAPACITY 5A/30VDC,5A/250VAC
CAN COMMUNICATION INTERFACE
1 CHANNEL:(DUPLEX/GROUP CONTROL, REMOTE WIRELESS MONITORING)
RS232 COMMUNICATION
INTERFACE
2 CHANNELS: DIGITAL OPERATOR/PC MONITORING/PROGRAMMABLE INTERFACE;
SECURITY DOG COMMUNICATION
D
ISPL
AY
DIGITAL OPERATOR
LCD DISPLAY IN CHINESE/ENGLISH
MONITORING SOFTWARE
INTERFACE
MENU/PARAMETER/STATE/VARIABLE TIMING/DIGITAL OSCILLOSCOPE ETC.
M
AIN PROTECTION FUNCT
IONS
INSTANTANEOUS OVERCURRENT
PROTECTION
STOP AT OVER 200% RATED OUTPUT CURRENT
FUSE PROTECTION
STOP AT FUSED
OVERLOAD PROTECTION
STOP AT 150% RATED CURRENT 60S/180% RATED CURRENT 10S
OVERVOLTAGE PROTECTION
STOPS AT DC BUS VOLTAGE OVER 720V (400V DRIVE) OR 410V (200V DRIVE)
UNDERVOLTAGE PROTECTION
STOPS AT DC BUS VOLTAGE UNDER 380V (400V DRIVE) OR 190V (200V DRIVE)
HEATSINK OVERHEAT PROTECTION
PROTECT BY THERMISTORS
IGBT INTERNAL PROTECTION
IGBT OVERCURRENT/OVERHEAT/SHORT CIRCUIT/UNDERVOLTAGE PROTECTION
MOTOR PROTECTION
PROTECT BY ELECTRONIC THERMAL DEVICES
IMPACT RESTRAINING CIRCUIT
PROTECT BY CONTACTOR FEEDBACK
OVERSPEED PROTECTION
PROTECT AT SPEED EXCEED THE MAXIMUM ALLOWABLE SETTING
SPEED DEVIATION PROTECTION
PROTECT AT SPEED DEVIATION EXCEEDS ALLOWABLE VALUE
PG FAULT PROTECTION
PROTECT AT PG DISCONNECTION/PHASE ERROR
AUTO TUNING PROTECTION
PROTECT AT AUTO TUNING FAULT
OPEN-PHASE PROTECTION
PROTECT AT INPUT/OUTPUT PHASE LOST
DOOR INTERLOCK FAULT
PROTECT AT DOOR INTERLOCK CIRCUIT OPEN WHEN RUNNING
SAFETY CIRCUIT FAULT
PROTECT AT SAFETY CIRCUIT OPEN WHEN RUNNING
BRAKE FAULT
NO BRAKE OPEN FEEDBACK SIGNAL AFTER OUTPUT BRAKE OPEN COMMAND
LEVELING ZONE SIGNAL FAULT
PROTECT AT LEVELING ZONE SIGNAL FAULT
M
AIN PROTECTION
FUNCTIONS
OUTPUT CONTACTOR FAULT
PROTECT AT OUTPUT CONTACTOR FAULT
RUNNING TIME PROTECTION
PROTECT AT SINGLE RUNNING TIME EXCEEDS LIMIT
FLOOR COUNTER FAULT
PROTECT AT FLOOR COUNTER FAULT
COMMUNICATION INTERFERENCE
FAULT
PROTECT AT COMMUNICATION INTERFERENCE FAULT
HOISTWAY PARAMETER LEARNING
FAULT
HOISTWAY PARAMETER LEARNING FAULT PROTECTION
S
TRUCTUR
E
PROTECTION DEGREE
C: CLOSED IP20; O: OPEN IP00
COOLING
FORCED AIR COOLING
INSTALLATION
CABINET EMBEDDED INSTALLATION/HANGING INSTALLATION
AMBIENT TEMPERATURE
-10 C~+40 C
U
SING
AMBIENT
HUMIDITY
5~95%RH, NO CONDENSATION
STORAGE TEMPERATURE
-20 C~+60 C
APPLICATION SITUATION
INDOOR (NO CORROSIVE GAS, FLAMMABLE GAS, DUST AND DIRECT SUNLIGHT)
ALTITUDE
BELOW 1000M
VIBRATION
10~20HZ, <9.8M/S²; 20~50HZ, <2M/S²
