BlueNova HC - Document Scope; Structural Overview; Product Range Dimensions and Weight; Included Packaging Components

User Manual
High Current Product Range
2 Erica Way  Office: +27 21 205 2000
Somerset West Business Park  Technical Support: support@bluenova.co.za
Somerset West, 7130  Website: www.bluenova.co.za
.
A. DOCUMENT SCOPE
Congratulations on purchasing a high quality BlueNova® product.
This document covers structural information, assembly & installation instructions, troubleshooting, safety &
maintenance instructions, storage guidelines as well as emergency / first aid procedures specific to the
BlueNova® High Current (HC) product range.
If you are unsure whether this document is applicable to your battery, or if you have any questions or comments,
kindly contact BlueNova® Technical Support:
 Office: +27 21 205 2000  E-mail: support@bluenova.co.za
B. STRUCTURAL OVERVIEW
The BlueNova® HC range consists of single- and multi-enclosure batteries. The number of enclosures per battery
as well as the weight & dimensions of each enclosure are listed below:
#
Product Name
Enclosures per battery
Qty
Dimensions L x W x H
Weight (total)
1
BN13V-240-3.2k HC
1
51 x 21 x 31cm
38kg
2
BN13V-480-6.3k HC
1
80 x 21 x 31cm
75kg
3
BN26V-125-3.3k HC
1
51 x 21 x 31cm
38kg
4
BN26V-240-6.3k HC
1
80 x 21 x 31cm
75kg
5
BN26V-480-12.5k HC
2
2 x (80 x 21 x 31cm)
160kg
6
BN52V-125-6.5k HC
1
80 x 21 x 31cm
75kg
7
BN52V-240-12.5k HC
2
2 x (80 x 21 x 31cm)
160kg
8
BN52V-480-25k HC
4
4 x (80 x 21 x 31cm)
320kg
The following components should be included in the packaging of each battery:
Product (V-Ah-kWh)
Bolt set*
Bus bar**
Terminal
sleeves
Fuse(s)
1
BN13V-240-3.2k HC
2
–
1 POS / 1 NEG
1 x 125A
2
BN13V-480-6.3k HC
2
–
1 POS / 1 NEG
2 x 160A
3
BN26V-125-3.3k HC
2
–
1 POS / 1 NEG
1 x 125A
4
BN26V-240-6.3k HC
2
–
1 POS / 1 NEG
2 x 125A
5
BN26V-480-12.5k HC
4
1
1 POS / 1 NEG
2 x 160A
6
BN52V-125-6.5k HC
2
–
1 POS / 1 NEG
1 x 125A
7
BN52V-240-12.5k HC
4
1
1 POS / 1 NEG
2 x 125A
8
BN52V-480-25k HC
8
3
1 POS / 1 NEG
2 x 160A
* One bolt set consists of 1 x bolt, 1 x washer & 1 x spring washer.
** Bus bars include positive (red) and negative (black) insulation sleeves.
