06
Battery Capacity LED
Show the remaining capacity of B300.
12V/10A Cigarette Lighter Port
Output port for devices with corresponding
plug such as vehicle-use vacuum.
USB-C (PD3.0, 100W) Output Port
Can be used via USB-C to USB-C cable to
charge most devices in the market such as
Pixel Phone, Macbook Pro at 100W Max.
To turn ON/OFF the output function of B300.
USB-A (QC3.0) Output Port
USB-A ports supports QC3.0 protocol.
Power Button
To turn ON/OFF the B300, all the function will
be closed.
Battery Extension Port
The port to connect B300 with AC300/
AC200MAX/B300.
PV Input Port
To charge B300 via solar powers.
And car charging, lead-acid battery charging.
Charger Input Port
To charge B300 via vehicle, extra solar power,
lead-acid battery, AC adaptor. Suitable for
D050S.
8. RECHARGE
8.1 Solar Charging
(PV Input Cable)
(SP200 Solar Panel)
To Next Page
