Charging
AC Charging
Simply plug the B300S into a standard wall outlet and start charging.
PV Charging
Connect the solar panels (in series or parallel) to B300S with the DC input cable.
Note:
Please make sure your solar panels comply with:
OCV
3
: 12-60V Vmp
4
: 12-60V Input Power: 500W Max
E.g: Connect two BLUETTI PV200 solar panels in series to charge the unit.
BLUETTI PV200: Voc=26.1V Vmp=20.5V Current=9.7A Max.
Total: Voc=26.1×2=52.2V Vmp=20.5×2=41V Current=9.7A Max.
3
OCV: Open circuit voltage, also for Voc. The maximum voltage that the solar panel can produce with no
load on it.
4
Vmp: Voltage at maximum power. The voltage available when the panel is operating at its peak
performance output.
AC Adapter
Wall Outlet
MC4 Connectors
DC Input Cable
4
3
2
1
1
4
3
2
13
