B300S Capacity Expansion Tutorial
AC500 + 6*B300S = 5000W Max. / 18432Wh
AC500 + 2*B300S = 5000W Max. / 6144Wh
Note:
Press the power button either on AC500 or B300S to turn on the AC500 + B300S combo.
When AC500 is connected to the grid or solar panels, the combo turns on automatically.
If there’s only one B300S connected, the combo delivers a maximum output of 4500W.
To get 5000W AC output, connect at least one expansion battery to each expansion port.
16
