Bluetti PS72 - Operation - Charging Methods; PV Charging; Car Charging

12
Connect the solar panels (in series or parallel) to PS72 via the solar charging cable.
Note: Please make sure your solar panels comply with:
OCV
3
: 12-28V Input Power: 200W Max.
E.g. Use one BLUETTI PV200 solar panel to charge the unit.
BLUETTI PV200: Voc=26.1V Vmp
4
=20.5V Current=9.7A Max.
PV Charging
Connect the PS72 directly to the vehicle plug-in cigarette lighter port via the car charging cable.
3
OCV: Open circuit voltage, also for Voc. The maximum voltage that the solar panel can produce with no load on it.
4
Vmp: Voltage at maximum power. The voltage available when the panel is operating at its peak performance output.
Car Charging
Car Charging Cable
MC4 Connectors
Solar Charging Cable
