a.NEMA L14-30: has an L-shaped neutral blade. available in ratings to 30A, allowing for
240V when supplied by split-phase power.
b. NEMA TT-30: connector which is the 120V/30 A recreational vehicle standard, also known
as RV 30. The TT-30R receptacle is commonly available in nearly all RV parks in the United
States and Canada.
c. Standard AC receptacle: wildly used in 100-120V areas, generates the almost same AC
power as a household wall outlet.
d.When Split Phase System installation finished successfully, both of the two LED lights
stay ALWAYS ON.
If the LED light is not active, please check the connection.
FEATURES OF P030A
- 04 -
a
b
c
d
