LCD Screen
LED Indicator (Green)
Power Button
DC Output (12V/5A)
USB-C Port
DC Output (16V/4A)
USB-A Port
DC Output (24V/4A)
Charging Port
Power devices with 12V input.
Power supported devices.
Power devices with 16V input.
Power supported devices.
Power devices with 24V input.
Charge X60 through this port.
1
2 3 4 5 6 7 8 9
3. Product Overview
X60 is a DC portable power bank with an internal integrated large capacity battery pack.
With external adapter charging and car charging, LCD screen, USB-A, USB-C and
12V/16V/24V DC output, it is suitable for CPAP power supply and mobile devices
charging. Refer to 6. Specifications for more details of X60.
The keys and interfaces of X60 are shown in the following figure.
Table 3-1 Descriptions of Keys and Interfaces
DescriptionNameNo.
1
2
3
4
5
6
7
8
9
Displays operation information
e.g. SoC and charging/discharging status.
Hold it for 3 seconds to power on/off X60.
Always on: X60 powered on; flashing: charging
JUST POWER ON 11
