BluClear manual

1 UV-C lamp holder 6 Quartz glass holder

2 Spiral ring 7 O-ring

3 Quartz glass 8 UV-C lamp PL

4 Swivel 9 Folder holder with built-in transformer

5 O-ring 10 Clip

1.B BGF-3611 & BGF-5211

1 Fountain head 8 UV-C light viewing

window

15 Manifold 22 Screw

2 Telescopic ris-

9 Upper filter cover 16 Filter material 23 Quartz glass

3 Swivel 10 Connection tube 17 Filter housing 24 O-ring

4 T-faucet 11 Filter sponge 18 Pump 25 Quartz glass holder

5 O-ring 12 Filter sponge-fine 19 Holder 26 UV-C lamp PL

6 Hose connec-

tion

13 Filter housing 20 Holder 27 Lampholder with

transformer and cable

7 Swivel 14 O-ring 21 UV-C lamp

housing
