blupura WAVE Touch - Internal Frontal View; Internal Component Identification

11
Internal Frontal View
1
32 4
5
6
7
8
5
6
7
8
2
3
4
1
General switch
Adjustable thermostat
Exit water solenoid valve
Removable exit water pipe
Ice bank inlet pipe joint Ø5/16”
(8 mm)
Inlet safety valve with check
valve and mechanical filter
Ø5/16” (8 mm)
Ice bank drainage pipe
CO
2
inlet pipe Ø5/16” (8 mm)
