23
Service Manual for RESmart
®
CPAP and AutoCPAP V1.5
S/N Name Qty Figure
21 Humidifier Plug (right-up) 1
22 Humidifier Plug (right-down) 1
23 Device Pad 6
24 Blower Connector 1
25 Humidifier Inner Connector 1
26 Key Button 1
27 Humidifier Scaleboard 1
28 Heater Plane Spring 3
29 Button Spring 1
