BMC RESmart

24
Service Manual for RESmart
®
CPAP and AutoCPAP V1.5
Part Name S/N Qty Unit Classify Use
Main Board PCBA 20211261 1 PC PCBA Main Device
Heater PCBA 20212-41 1 PC PCBA Humidifier
Power Supply PCBA 20311101 1 PC PCBA Main Device
Blower 40211 1 PC Assembly Main Device
Heater Plane 45010101 1 Set Assembly Humidifier
Power Supply PCBA Wire 45010201 1 Set Wire Main Device
Main Board PCBA Wire 45010301 1 Set Wire Main Device
Silicon Rubber Canal 50224 1 PC Assembly Main Device
Silicon Rubber Canal 50224 1 PC Assembly Main Device
Foam (bottom) 40191-0101 1 PC Foam Main Device
Foam (cover) 40191-0201 1 PC Foam Main Device
Shield Cover 4011120101 1 PC Plastic Main Device
Handle 4011120201 1 PC Plastic Main Device
Handle Fixing 40111-0301 2 PC Plastic Main Device
Shield Bottom 4011120401 1 PC Plastic Main Device
Humidifier Clip 4011120501 1 PC Plastic Main Device
Humidifier Locker 40111-0601 1 PC Plastic Main Device
Humidifier Fixing 40111-0701 1 PC Plastic Main Device
Filter Cover 4011120801 1 PC Plastic Main Device
Shield Back 4011120901 1 PC Plastic Main Device
Outlet 4011123001 1 Set Plastic Main Device
PCBA Fixing 40111-1301 2 PC Plastic Main Device
Infrared Window 4011101401 2 PC Plastic Main Device
Panel 4011220101 1 PC Plastic Main Device
Power Supply PCBA Fixing 40111-1601 1 PC Plastic Main Device
Humidifier Outer Shield 4011122201 1 PC Plastic Humidifier
Humidifier Inner Shield 4011122301 1 PC Plastic Humidifier
Pole Platelet 40111-2601 1 PC Plastic Humidifier
Light Window 4011142401 1 PC Plastic Humidifier
Button Spring 4013140101 1 PC Metal Main Device
Humidifier Scaleboard 4013130401 1 PC Metal Humidifier
Heater Plane Spring 4013140501 3 PC Metal Humidifier
Humidifier Power Plug 4012110101 1 PC Rubber Main Device
Humidifier Plug (left-up) 4012110201 1 PC Rubber Main Device
Humidifier Plug (left-down) 4012110301 1 PC Rubber Main Device
Humidifier Plug (right-up) 4012110401 1 PC Rubber Main Device
Humidifier Plug (right-down) 4012110501 1 PC Rubber Main Device
Device Pad 4012110601 6 PC Rubber All
Key Button 4012110701 1 PC Rubber Main Device
Blower Connector 4012110801 1 PC Rubber Main Device
Spare Part List
