BMC TMR01 User Manual

Recommended spacer installation (with new brake pads):
Description Part N°
Front pad set 210536
Rear pad set 210537
1 Brake pad
2 Socket
3 0.5mm spacer
4 1.2mm spacer
5 2mm spacer
6 Brake pad bolt
Rim width Spacers (per side)
Zipp 808 26 -1.5 (pads grinded)
23 0
22 0.5
21 1 = 0.5 + 0.5
Easton /
Shimano
20.6 1.2
19.6 1.7 = 1.2 + 0.5
Mavic (standard
alloy wheels)
19 2
18.6 2.2 = 1.5 + 0.5 + 0.5
18 2.5 = 2 + 0.5
3 different spacers are delivered with the bike:
0.5mm (x2), 1.2mm, 2mm
22 | 23
Building
1
2
5
6
4 3
Building a timemachine
