The following instructions will help you to install the Di2 cables inside the timemachine frame, it will not guarantee a proper function of
your groupset.
Therefore, before installation, we recommend you to read the instructions provided by Shimano.
Description Part N°
1 Battery cover 210543
2 Cable stop cover 210996
Di2 shifting
The timemachine frameset is 100% compatible and retrocompatible with mechanical (Shimano, Sram and Campagnolo) and electronic
(Shimano) groupsets.
Connector
Hole
Junction (SM-JC41)
1
2
