BMG LABTECH SPECTROstar Nano Operating Manual
2012-07-18 0601B0001C 5/16
1 Technical Specifications
Detection Mode
- UV/Vis Absorbance Spectra
Measurement Modes
- Endpoint and Kinetic measurements
- Well Scanning
Microplate Formats
- 6 to 1536-well plates, user definable
Microplate Carrier
- Auto lock microplate carrier
- Robot compatible
- All microplate formats up to 1536-well
Microplates should adhere to the SBS specification and non-SBS
formats should fit: (l x w x h) (mm) max: 128x86x20; min: length 124
Cuvette Port
- Cuvette port for cuvettes with 10 mm path length
- Micro cuvettes, Traycell compatible
- Beam height 8,5 mm
Light Source
- High energy xenon flash lamp
Detector
- Spectrometer with CCD
Spectral Range
- 220 - 1000 nm for ABS (Absorbance Spectrometer)
Sensitivity
- ABS with Spectrometer Selectable
Spectral resolution: 1 nm, 2 nm, 5 nm, 10 nm
OD range: 0 – 4 OD
Accuracy: < 1% at 2 OD
Precision: < 0.5% at 1 OD and < 0.8% at 2 OD
Read Times
- Full spectrum from 220 to 1000 nm in less than 1 sec/well
Shaking
- Linear, orbital, and double-orbital with user-definable time and
speed
Incubation
+3°C above ambient up to 45°C for microplate and cuvette
Software
- Multi-user Reader Control and MARS Data Analysis Software
included
Computer interface
- USB 2.0, compatible to USB 1.1
Power requirements
- External Power Supply: Type: XP Power AEF120PS24
- Input Voltage: 100 or 115 or 230 V, 50/60 Hz, auto ranging
- Output Voltage: 24V DC / 5A
