14
Dormer
window
Fig 5. Pitch roof, chimney within
1.5 m from dormer window
measured horizontally
Not less than 600 mm
Not Less
than
1000 mm
Less than 45°
Fig 4. Pitch roof, internal route, pitch not
exceeding 45° and ridge termination
Not less than
600 mm
Termination
on ridge
Fig 3. Pitched roof, exceeding 45°
Greater than 45°
Not less than
1000 mm
Not less
than
1000mm
Dormer
window
Fig 2. Pitched roof, within
1.5 m of a structure on roof
Not
Less
than
600mm
Less than
1500 m
Terminals must not be positioned
within 1.5m of the wall surface
Not less than
600 mm
Not greater than 45°
Fig 1. Pitched roof, not greater than 45°
Not less
than
600 mm
