BMP EASY 01 - Page 2

Update sw via trastier with micro SD (formatted FAT32 if new), capacity maximum SD 2Gb,
update file name: inv_star.enc (without folders)
NET FUSE
NETWORK INPUT
POWER SUPPLY
MOTOR OUTPUT
THREE-PHASE
FLASHING OUTPUT
(DRY CONTACT)
Inputs /Connection to
PULS_3 interface
LED status indication
inputs
Power supply +\- 12Vdc
and serial communication
BRAKE OUTPUT
DIP SWITCH
2 WAYS
Led activity
microcontroller
Led indicatore
scarica
condensatori BUS
Led presence
power supply
12Vdc
2
